True GDM Series User Manual

41
REQUIRED TOOLS
• Phillips Head Screwdriver
• Drill
• 1/8" Drill Bit
__________ STEP 1 __________
Disconnect the power supply,
unload contents of cabinet and lay
cabinet on its back.
__________ STEP 2 __________
Remove the lower louvered grill.
Remove the stainless steel skirt
around the louvered grill.
__________ STEP 3 __________
Remove the sign on the louver sec-
tion above the door (s).
__________ STEP 4 __________
Remove hinges and door (s).
__________ STEP 5 __________
Drill out pop rivet on right top cor-
ner of plastic and stainless steel
mullion trim. Remove the top hori-
zontal stainless steel strip by sliding
it to the right of the tracks in the
plastic. Be sure to raise the corner
of the plastic trim where the pop
rivet was removed so that the stain-
less trim slides beneath it. Drill out
the two pop rivets in the top plastic
trim which was hidden by the hori-
zontal piece of stainless trim.
__________ STEP 6 __________
Remove left and right vertical
stainless steel trim pieces by sliding
them out of the plastic trim. Be
sure to raise the top horizontal plas-
tic trim piece so that the stainless
trim passes underneath it toward
the top of the cabinet.
__________ STEP 7 __________
Drill out the pop rivet that was hid-
den by the stainless steel trim in the
lower right corner of the vertical
plastic piece so that the lower verti-
cal stainless trim slides beneath it
for removal.
__________ STEP 8 __________
Disconnect heater wires in the junc-
tion box. Remove heater wire loop
by unhooking at the corners where
it is retained by the plastic trim
pieces.
__________ STEP 9 __________
Replace inoperative heater wire loop,
being sure to hook under the corners
of the plastic trim as observed during
d i s a s s e m b l y.
__________STEP 10 __________
Reverse assembly sequence to
replace trim. Use the four (4) small
sheet metal screws furnished with
the heater wire in the same
sequence as the pop rivets were
removed.
__________ STEP 11 __________
Attach the heater wires to the power
supply in junction box. Replace all
other assemblies in reverse
sequence in which they were
removed.
INSTALLATION INSTRUCTION
GDM AND T-SERIES FREEZER PERIMETER HEATER WIRE REPLACEMENT

True GDM Series Specifications

General

Defrost Type	Automatic
Weight	Varies by model
Shelves	Adjustable Wire Shelves
Lighting	LED
Interior Finish	Stainless Steel
Compressor Location	Bottom
Energy Efficiency	Energy Star Certified
Capacity	Varies by model
Dimensions	Varies by model
