TSC TDP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 70 Copyright 2013 All Rights Reserved.
RSS 410,10,"UPCE",0,2,2,"001220000456|ABCDEFG"
PRINT 1
SIZE 4,1
GAP 0,0
DIRECTION 1
CLS
REM UPCE Rule 2: 00abc00000ij = abcij3
RSS 10,10,"UPCE",0,2,2,"001230000045|ABCDEFG"
PRINT 1
SIZE 4,1
CLS
REM UPCE Rule 3: 00abcd00000j = abcdj4
RSS 10,10,"UPCE",0,2,2,"001234000005|ABCDEFG"
PRINT 1
SIZE 4,1
GAP 0,0
DIRECTION 1
CLS
REM UPCE Rule 4: 00abcde0000j = abcdej where j = 5-9
RSS 10,10,"UPCE",0,2,2,"001234500005|ABCDEFG"
RSS 160,10,"UPCE",0,2,2,"001234500006|ABCDEFG"
RSS 310,10,"UPCE",0,2,2,"001234500007|ABCDEFG"
RSS 460,10,"UPCE",0,2,2,"001234500008|ABCDEFG"
RSS 610,10,"UPCE",0,2,2,"001234500009|ABCDEFG"
PRINT 1
Example of barcode height of EAN8 EAN13 UPCA and UPCE.
SIZE 4,2
GAP 0,0
DIRECTION 1
CLS
RSS 10,10,"EAN8",0,1,1,"1234567|ABCDEFG"
RSS 210,10,"EAN8",0,2,1,"1234567|ABCDEFG"
RSS 410,10,"EAN8",0,3,1,"1234567|ABCDEFG"
PRINT 1
SIZE 4,2
GAP 0,0
DIRECTION 1
CLS
RSS 10,10,"EAN13",0,1,1,"123456789012|ABCDEFG"
RSS 210,10,"EAN13",0,2,1,"123456789012|ABCDEFG"
RSS 410,10,"EAN13",0,3,1,"123456789012|ABCDEFG"
PRINT 1
SIZE 4,2
GAP 0,0
DIRECTION 1
CLS
RSS 10,10,"UPCA",0,1,1,"12345678901|ABCDEFG"
RSS 210,10,"UPCA",0,2,1,"12345678901|ABCDEFG"
RSS 410,10,"UPCA",0,3,1,"12345678901|ABCDEFG"
