TSC TTP-245

TTP-245 / TTP-343
64
4. Open the printer top cover by pushing the top cover open levers to the paper
outlet direction. The top cover support will hold the printer top cover.
5. Open the top cover to the ultimate open angle. Push the top cover support to the
communication port direction to disconnect the lower inner cover and top cover
support.
Cutter Driver IC
Top cover
support
