16.SPECIFICATIONS
109
16. SPECIFICATIONS
16-1. Analog Section
Sensor excitationvoltage 10V or 2.5V DC±10%
(The factory-shipped initial value is 2.5V.)
Output current within 30mA
Signal input range -3.0 to +3.0mV/V
Equivalent input calibration range +0.5 to +3.0mV/V
Equivalent input calibration error Within 0.1％FS（0.5mV/V input）
Zero adjustment range 0 to ± 2.0mV/V
Gain adjustment range +0.5 to +3.0mV/V
Analog input signal sensitivity 1μV/count
(1/10000 can be assured with 1mV/V
or more input.)
Accuracy Non-linearity Within 0.02%FS
（of 3mV/V input）
Zero drift Within 0.5μV/ ℃
Gain drift Within 25ppm/ ℃
A/D converter 2000 times /sec. Resolution:24 bits （binary）
Analog filter 3, 10, 30, 100, 300, 1kHz
Peak hold function Digital peak hold at 2000 times/sec.
