10.BCD DATA OUTPUT
85
10-3. Source Type (BSC Option)
Output
Output signal: Indicated value data (5-digit), near zero, minus, over,
stable, strobe
Output logic: Switching between positive logic and negative logic
Output type: Source type
When signal ON, output transistor ON.
When the input unit such as PLC is connected, minus common
is connected.
Rated voltage: 30V
Rated current: 20mA
Insulation method: Photo coupler insulation
Input
Input signal: BCD data hold, logic switching
Input type: Minus common
When the transistor is connected, PNP output type (source type)
is connected.
ON voltage: 9V or more
OFF voltage: 3V or less
At 24V load: About 5mA
Insulation method: Photo coupler insulation
To Next Page
