1FUNCTIONAL DESCRIPTIONS
5
1-2. Rear Panel
1-2-1. Protective Ground
This is a protective ground terminal block. Be sure to ground the protective
ground terminal to prevent electric shocks and failures by static electricity. (The
frame and protective ground terminal are conducted.) Do not use other screws
than that attached to the main body (M4×8 binding-head machine screw with a
toothed washer).
1-2-2. Frame Ground (Frame terminal)
This is a F.G terminal.（The frame and the F.G terminal are conducted.）
1-2-3. Options Slot
One option board can in stall in the option slot.
• BCD Parallel data output （BCO）
• D/A Converter（voltage output）（DAV）
• D/A Converter（current output）（DAI）
Option SlotFrame Ground
AC Input
Protective Ground
Terminal Block
