10.BCD DATA OUTPUT
82
10-2-2. Connector Pin Assignment
Compatible connector:
FCN-361J032-AU (manufactured by Fujitsu Component or an equivalent)
Connector cover
:
FCN-360C032-B (manufactured by Fujitsu Component or an equivalent)
Near Zero
The state of near zero is outputted.
Minus (polarity)
The polarity of the indicated value as BCD data is outputted.
No. Signal No. Signal
A1
＊
COM B1
＊
COM
A2 Out 1 B2 Out 1000
A3 Out 2 B3 Out 2000
A4 Out 4 B4 Out 4000
A5 Out 8 B5 Out 8000
A6 Out 10 B6 Out 10000
A7 Out 20 B7 Out
A8 Out 40 B8 Out
A9 Out 80 B9 Out Near Zero
A10 Out 100 B10 Out Minus (polarity)
A11 Out 200 B11 Out Over
A12 Out 400 B12 Out P.C(stable)
A13 Out 800 B13 Out Strobe
A14 In BCD Data Hold B14 In Logic Switching
A15 B15
A16 B16
