4.SETTING MODE CONFIGURATION
25
4-3. List of Values
Setting Mode1
*Decimal point position synchronizes with the setting of decimal place of setting mode 3.
Setting Mode2
Item Default Setting range Set Value
LOCK
Calibration
LOCK
Reference
page
1
High Limit
075.00
-19999 to 19999 *
○
P.42
2
Low Limit
025.00
-19999 to 19999 *
○
P.42
3
High/Low Limit
Comparison Mode
0
3 : Comparison is made at stable
status except for near zero.
2 : Comparison is always made
except for near zero
1 : Comparison is made in the
stabl status.
0 : Comparison is always made.
○
P.45
4
Hysteresis
00.00
0000 to 9999 *
○
P.46
5
Digital Offset
000.00
-19999 to 19999 *
○
P.49
6
Near Zero
001.00
00000 to 19999 *
○
P.50
Item Default Setting range Set Value
LOCK
Calibration
LOCK
Reference
page
1
Digital Filter
020 000 to 256
○
P.51
2
Analog Filter
3
5 : 1kHz
4 : 300Hz
3 : 100Hz
2 : 30Hz
1 : 10Hz
0 : 3Hz
○
P.52
3
Motion Detect（time）
1.5 0.0 to 9.9
○
P.53
4
Motion Detect（range）
05 00 to 99
○
P.53
5
Zero Tracking（time）
0.0 0.0 to 9.9
○
P.55
6
Zero Tracking（range）
00 00 to 99
○
P.55
7
Hold Mode
0
1 : Peak Hold
0 : Sample Hold
○
P.57
