13.OVERSCALE/ERROR DISPLAYS
100
13. OVERSCALE/ERROR DISPLAYS
13-1. Overscale Display
13-2. Calibration Error Display
Minus overflow of the A/D converter
（under -3.2mV/V between ± SIG）
Plus overflow of the A/D converter
（over 3.2mV/V between ± SIG）
Indicated value overflowed
（indicated value<-19999）
Indicated value overflowed
（indicated value>19999）
Output of the strain gauge sensor does not
reach the span adjustment range.
Output of the strain gauge sensor is on the
minus（negative）side.
