7HOLD FUNCTION
67
• Timing Chart
t1 : Time from when the hold signal is inputted to when the indicated value is
held
t2 : Time from when the hold signal is cancelled to when the indicated value
returns to tracking
t3 : Minimum reset signal width required for canceling the hold
t2
t3
Detection/Hold Section
Time
Detection/Hold
t1t2t1
t3
OFF
ON
Hold
Indicated value
Sensor input value
t1 to t3 : MAX 5mS
input
Section
