Uponor Smatrix Wave PULSE User Manual

Thermostatic head T-162
ERM (electromagnetic compatibility and radio spectrum matters) tests EN 300 220-3
Power supply Two 1.5 V AA alkaline batteries
Voltage 2.2 V to 3.6 V
Rated impulse voltage 0.33 kV, OVC I
Pollution degree 2
Software class A
Maximum stroke 3.5 mm
Maximum strength 70 N
Differential pressure 1.5 bar
Operating temperature 0 °C to +40 °C
Storage temperature -10 °C to +50 °C
Radio frequency 868.3 MHz
Radio frequency, EAC markets only 869 MHz
Transmitter duty cycle <1%
Relay module M-161
IP IP20, class II (IP: degree of inaccessibility to active parts of the product
and degree of water)
Max. ambient RH (relative humidity) 85% at 20 °C
CE marking
ERP IV
Low voltage tests EN 60730-1* and EN 60730-2-1**
EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3
ERM (electromagnetic compatibility and radio spectrum matters) tests EN 300 220-3
Power supply 230 V AC +10/-15%, 50 Hz or 60 Hz
Pollution degree 2
Software class A
Operating temperature 0 °C to +50 °C
Storage temperature -20 °C to +70 °C
Maximum consumption 2 W
Radio frequency 868.3 MHz
Radio frequency, EAC markets only 869 MHz
Transmitter duty cycle <1%
Relay outputs 230 V AC +10/-15%, 250 V AC 2.5 A maximum
Micro gap, normally open
Power connection 1 m flexible cord, with europlug (except UK), which is connected to the
relay module
Connection terminals Up to 4.0 mm² solid, or 2.5 mm² flexible with ferrules
Antenna
IP IP20, class III (IP: degree of inaccessibility to active parts of the product
and degree of water)
Max. ambient RH (relative humidity) 85% at 20 °C
CE marking
Power supply From room controller
Radio frequency 868.3 MHz
Radio frequency, EAC markets only 869 MHz
Transmitter duty cycle <1%
Receiver class 2
Communication module R-208
IP IP20, class III (IP: degree of inaccessibility to active parts of the product
and degree of water)
Max. ambient RH (relative humidity) 85% at 20 °C
CE marking
Low voltage tests EN 60730-1* and EN 60730-2-9***
EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3
ERM (electromagnetic compatibility and radio spectrum matters) tests EN 300 220-3
Power supply From room controller
112
|
Uponor Smatrix Wave PULSE
|
Installation and operation manual

Uponor Smatrix Wave PULSE Specifications

General

Type	Wireless Temperature Controller
Communication Protocol	RF (Radio Frequency)
Compatibility	Uponor Smatrix Wave system
Operating Temperature Range	0°C to 50°C
Display	LCD
Control	Wireless
