18.4 Wiring diagram
Uponor Smatrix Wave PULSE room controller
WD0000019
GPI
> 40 cm
RELAY 2 (BOILER)
RELAY 1
(PUMP)
GPI 1
GPI
GPI 2
GPI 3
Uponor Smatrix Wave PULSE slave module
WD0000020
18.5 Dimensions
Uponor Smatrix Wave PULSE room controller
336 mm
245 mm84 mm
72,5 mm 110 mm
110 mm
80 mm
55 mm
CD0000119
Uponor Smatrix Wave PULSE
|
Installation and operation manual
|
115
