Uponor Smatrix Wave PULSE User Manual

Communication module R-208
Pollution degree 2
Software class A
Operating temperature 0 °C to +45 °C
Storage temperature -20 °C to +70 °C
Wi-Fi connectivity 802.11 b/g/n @2.4Ghz
Wi-Fi security WPA & WPA2
Radio frequency 868.3 MHz
Radio frequency, EAC markets only 869 MHz
Transmitter duty cycle <1%
Receiver class 2
Connection terminals RJ45 Ethernet connection (10/100BaseT)
Room controller X-265
IP IP20, class II (IP: degree of inaccessibility to active parts of the product
and degree of water)
Max. ambient RH (relative humidity) 85% at 20 °C
CE marking
ERP (with communication module and the Uponor Smatrix PULSE app) VIII
ERP (without communication module and the Uponor Smatrix PULSE
app)
IV
Low voltage tests EN 60730-1* and EN 60730-2-9***
EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3
ERM (electromagnetic compatibility and radio spectrum matters) tests EN 300 220-3
Power supply 230 V AC +10/-15%, 50 Hz or 60 Hz
Internal fuse T5 F3.15AL 250 V, 5x20 3.15A quick acting
Rated impulse voltage 2.5 kV, OVC II
Pollution degree 2
Software class A
Operating temperature 0 °C to +45 °C
Storage temperature -20 °C to +70 °C
Maximum consumption 45 W
Pump and boiler relay outputs 230 V AC +10/-15%, 250 V AC 8 A maximum
Micro gap, normally open
General purpose input (GPI) Only dry contact
Valve outputs 24 V AC, 0.2 A average, 0.4 A peak
Power connection 1 m flexible cord, with europlug (except UK), which is connected to the
controller
Connection terminals for power, pump, GPI and boiler Up to 4.0 mm² solid, or 2.5 mm² flexible with ferrules
Connection terminals for valve outputs 0.2 mm² to 1.5 mm²
*) EN 60730-1 Automatic electrical controls for household and similar
use -- Part 1: General requirements
**) EN 60730-2-1 Automatic electrical controls for household and
similar use -- Part 2-1: Particular requirements for electrical controls
for electrical household appliances
***) EN 60730-2-9 Automatic electrical controls for household and
similar use -- Part 2-9: Particular requirements for temperature
sensing controls
Usable in all Europe
Declaration of conformity:
We hereby declare under our own responsibility that products dealt with
by these instructions satisfy all essential demands linked to the
information stated in the Safety instruction booklet.
(869 MHz only)
18.2
Cable specifications
Cables Standard cable length Maximum cable length Wire gauge
Cable from room controller to
antenna
3 m 5 m CAT.5e or CAT.6, RJ 45 connector
Cable from room controller to
communication module
2 m 5 m CAT.5e or CAT.6, RJ 45 connector
Cable from room controller to
actuator
0.75 m 20 m Room controller: 0.2 mm² to 1.5
mm²
External sensor cable to thermostat 5 m 5 m 0.6 mm²
Uponor Smatrix Wave PULSE
|
Installation and operation manual
|
113

Uponor Smatrix Wave PULSE Specifications

General

Type	Wireless Temperature Controller
Communication Protocol	RF (Radio Frequency)
Compatibility	Uponor Smatrix Wave system
Operating Temperature Range	0°C to 50°C
Display	LCD
Control	Wireless
