Uponor Smatrix Wave PULSE User Manual

Uponor Smatrix Wave T-168
To enter the settings menu:
1. Press and hold the OK button for about 3 seconds.
2. The settings icon and menu numbers is displayed in the top right
corner of the display.
3. Use buttons - or + to change the numbers to locate a submenu
(see list below).
00
Program
02
Heating/cooling changeover
This menu is not visible if the thermostat is registered to a room
controller.
03
ECO mode setback temperature
04
Control mode
05
High floor temperature limitation
06
Low floor temperature limitation
07
Cooling allowed
08
Display unit
09
Climatic controller integration
10
Time and date
11
Room temperature calibration
4. Press OK to enter parameter edit mode.
The parameter starts flashing.
5. Change parameters in the submenus.
6. Press and hold the OK button for about 3 seconds to exit the
settings menu.
Uponor Smatrix Wave T-169
To enter the settings menu:
1. Press and hold the OK button for about 3 seconds.
2. The settings icon and menu numbers is displayed in the top right
corner of the display.
3. Use buttons
or to change the numbers to locate a submenu
(see list below).
02
Heating/cooling changeover
This menu is not visible if the thermostat is registered to a room
controller.
03
ECO mode setback temperature
04
Control mode
05
High floor temperature limitation
06
Low floor temperature limitation
07
Cooling allowed
08
Display unit
09
Climatic controller integration
11
Room temperature calibration
12
Invert screen
4. Press OK to enter parameter edit mode.
The menu number is underlined.
5. Change parameters in the submenus.
6. Press and hold the OK button for about 3 seconds to exit the
settings menu.
00 Program (T-168 only)
Note
As long as scheduling (program 00) is activated (not set
to Off) in a programmable digital thermostat, no other
unit is allowed to change (override) the Comfort/ECO
mode in that room.
In this menu, one of seven different scheduling programs for
Comfort/ECO mode can be set.
Program 1 to 6 is pre-programmed and the 7th is user defined. The
scheduled programs show the day split into 30 minute intervals which
is set to either Comfort (black marker) or ECO mode (blank marker).
This menu is not visible if a communication module is connected to
the system. Settings are referred to the Uponor Smatrix PULSE app.
If Off (default) is selected, the room follows the current system
Comfort/ECO mode.
Uponor Smatrix Wave PULSE
|
Installation and operation manual
|
91

Uponor Smatrix Wave PULSE Specifications

General

Type	Wireless Temperature Controller
Communication Protocol	RF (Radio Frequency)
Compatibility	Uponor Smatrix Wave system
Operating Temperature Range	0°C to 50°C
Display	LCD
Control	Wireless
