Vacon NX series Applications Manual

Table 66: Analogue output 1 (Control keypad: Menu M2 -> G2.3.5)
Index Parameter Min Max Unit Default Cust ID Description
P2.3.5.6
Analogue output 1
scale
10 1000 % 100 311
P2.3.5.7
Analogue output 1
offset
-100.00 100.00 % 0.00 375
* = Use TTF method to program these parameters.
Table 67: Analogue output 2 (Control keypad: Menu M2 -> G2.3.6)
Index Parameter Min Max Unit Default Cust ID Description
P2.3.6.1 *
Analogue output 2
signal selection
0.1 E.10 0.1 471
TTF programming
method used. See
Chapter 8.9 "Ter-
minal to function"
(TTF) programming
principle.
P2.3.6.2
Analogue output 2
function
0 15 4 472
See P2.3.5.2
P2.3.6.3
Analogue output 2
filter time
0.00 10.00 s 1.00 473
0 = No filtering
P2.3.6.4
Analogue output 2
inversion
0 1 0 474
0 = Not inverted
1 = Inverted
P2.3.6.5
Analogue output 2
minimum
0 1 0 475
0 = 0 mA (0 V)
1 = 4 mA (2 V)
P2.3.6.6
Analogue output 2
scale
10 1000 % 100 476
P2.3.6.7
Analogue output 2
offset
-100.00 100.00 % 0.00 477
* = Use TTF method to program these parameters.
MULTI-PURPOSE CONTROL APPLICATION VACON · 163
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
6

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
