Vacon NX series - Prohibit Frequency Parameters (Control Keypad: Menu M2 -> G2.5)

Table 8: Drive control parameters, G2.4
Index Parameter Min Max Unit Default Cust ID Description
P2.4.9
DC braking time
at stop
0.00 600.00 s 0.00 508
0 = DC brake is off
at stop
P2.4.10
Frequency to start
DC braking during
ramp stop
0.10 10.00 Hz 1.50 515
P2.4.11
DC braking time
at start
0.00 600.00 s 0.00 516
0 = DC brake is off
at start
P2.4.12 * Flux brake 0 1 0 520
0 = Off
0 = On
P2.4.13
Flux braking cur-
rent
0.00 I
L
A I
H
519
2.4.6 PROHIBIT FREQUENCY PARAMETERS (CONTROL KEYPAD: MENU M2 -> G2.5)
Table 9: Prohibit frequency parameters, G2.5
Index Parameter Min Max Unit Default Cust ID Description
P2.5.1
Prohibit frequency
range 1 low limit
0.00 320.00 Hz 0.00 509
P2.5.2
Prohibit frequency
range 1 high limit
0.00 320.00 Hz 0.00 510
P2.5.3
Prohibit acc./dec.
ramp
0.1 10.0 x 1.0 518
