6.4.4 OUTPUT SIGNALS
Table 62: Delayed digital output 1 (Keypad: Menu M2 -> G2.3.1)
Index Parameter Min Max Unit Default Cust ID Description
P2.3.1.1 *
Digital output 1
signal selection
0.1 E.10 0.1 486
TTF programming
method used. See
Chapter 8.9 "Ter-
minal to function"
(TTF) programming
principle. Possible
to invert with
ID1084 (NXP only).
MULTI-PURPOSE CONTROL APPLICATION VACON · 155
