Vacon NX series Applications Manual

Table 62: Delayed digital output 1 (Keypad: Menu M2 -> G2.3.1)
Index Parameter Min Max Unit Default Cust ID Description
P2.3.1.2
Digital output 1
function
0 29 1 312
0 = Not used
1 = Ready
2 = Run
3 = Fault
4 = Fault inverted
5 = FC overheat
warning
6 = Ext. fault or
warning
7 = Ref. fault or
warning
8 = Warning
9 = Reverse
10 = Jogging spd
selected
11 = At speed
12 = Mot. regulator
active
13 = Freq. limit 1
superv.
14 = Freq. limit 2
superv.
15 = Torque limit
superv.
16 = Ref. limit
supervision
17 = External
brake control
18 = I/O control
place act.
19 = FC temp. limit
superv.
20 = Reference
inverted
21 = Ext. brake
control inverted
22 = Therm. fault
or warn.
23 = On/Off control
24 = Fieldbus DIN
1
25 = Fieldbus DIN
2
26 = Fieldbus DIN
3
27 = Temp.Warn-
ing
NXS drives
only:
28 = Temp.Fault
NXP drives
only:
29 = ID.Bit
VACON · 156 MULTI-PURPOSE CONTROL APPLICATION
6
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
