Table 43: Keypad control parameters, M3
Index Parameter Min Max Unit Default Cust ID Description
P3.1 Control place 1 3 1 125
1 = I/0 terminal
2 = Keypad
3 = Fieldbus
P3.2 Keypad reference P2.1.1 P2.1.2 Hz 0.00
P3.3
Direction (on key-
pad)
0 1 0 123
You can adjust the
frequency refer-
ence on the keypad
with this parame-
ter.
P3.4 PID reference 0.00 100.00 % 0.00 167
P3.5 PID reference 2 0.00 100.00 % 0.00 168
R3.4 Stop button 0 1 1 114
0 = Limited func-
tion of Stop button
1 = Stop button
always enabled
5.4.11 SYSTEM MENU (CONTROL KEYPAD: MENU M6)
For parameters and functions related to the general use of the AC drive, such as application
and language selection, customised parameter sets or information about the hardware and
software, see the product's User Manual.
5.4.12 EXPANDER BOARDS (CONTROL KEYPAD: MENU M7
The M7 menu shows the expander and option boards attached to the control board and board
related information. For more information, see the product's User Manual.
PID CONTROL APPLICATION VACON · 125
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
5

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
