Vacon NX series - Output Signals

3.4.4 OUTPUT SIGNALS (CONTROL KEYPAD: MENU M2 -> G2.3
Table 17: Output signals, G2.3
Index Parameter Min Max Unit Default Cust ID Description
P2.3.1
AO1 signal selec-
tion
0.1 E.10 A11 464
TTF programming
method used. See
Chapter 8.9 "Ter-
minal to function"
(TTF) programming
principle.
P2.3.2
Analogue output
function
0 8 1 307
0 = Not used (20
mA/10V)
1 = Output freq. (0-
f
max
)
2 = Freq. refer-
ence (0-f
max
)
3 = Motor speed
(0-Motor nominal
speed)
4 = Motor current
(0-I
nMotor
)
5 = Motor torque
(0-T
nMotor
)
6 = Motor power
(0-P
nMotor
)
7 = Motor voltage
(0-U
nMotor
)
8 = DC-link volt
(0-1000V)
P2.3.3
Analogue output
filter time
0.00 10.00 s 1.00 308
0 = No filtering
P2.3.4
Analogue output
inversion
0 1 0 309
0 = Not inverted
1 = Inverted
P2.3.5
Analogue output
minimum
0 1 0 310
0 = 0 mA (0 V)
1 = 4 mA (2 V)
P2.3.6
Analogue output
scale
10 1000 % 100 311
