Table 69: Drive control parameters, G2.4
Index Parameter Min Max Unit Default Cust ID Description
P2.4.20 Modulator type 0 1 0 1516
Parameter for
changing the mod-
ulator type.
P2.4.21 Ramp; Skip S2 0 1 0 1900
This function is
used to bypass the
second corner S
ramp (i.e. to avoid
the unnecessary
speed increase,
the blue line in
Fig. 90 Ramp; Skip
S2) when the refer-
ence is changed
before the final
speed is reached.
Also S4 is
bypassed when
reference is
increased while
speed is ramping
down.
* = Parameter value can only be changed aftr the FC has been stopped.
6.4.6 PROHIBIT FREQUENCY PARAMETERS (CONTROL KEYPAD: MENU M2 -> G2.5)
Table 70: Prohibit frequency parameters, G2.5
Index Parameter Min Max Unit Default Cust ID Description
P2.5.1
Prohibit frequency
range 1 low limit
-1.00 320.00 Hz 0.00 509
0 = Not used
P2.5.2
Prohibit frequency
range 1 high limit
0.00 320.00 Hz 0.00 510
0 = Not used
P2.5.3
Prohibit frequency
range 2 low limit
0.00 320.00 Hz 0.00 511
0 = Not used
P2.5.4
Prohibit frequency
range 2 high limit
0.00 320.00 Hz 0.00 512
0 = Not used
P2.5.5
Prohibit frequency
range 3 low limit
0.00 320.00 Hz 0.00 513
0 = Not used
P2.5.6
Prohibit frequency
range 3 high limit
0.00 320.00 Hz 0.00 514
0 = Not used
P2.5.7
Prohibit acc./dec.
ramp
0.1 10.0 x 1.0 518
MULTI-PURPOSE CONTROL APPLICATION VACON · 167
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
6

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
