3.4.5 DRIVE CONTROL PARAMETERS (CONTROL KEYPAD: MENU M2 -> G2.4
Table 18: Drive control parameters, G2.4
Index Parameter Min Max Unit Default Cust ID Description
P2.4.1 Ramp 1 shape 0.0 10.0 s 0.1 500
Smooth ratio for S-
curves.
0 = Linear
100 = full acc/dec
inc/dec tmes
P2.4.2 Ramp 2 shape 0.0 10.0 s 0.0 501
Smooth ratio for S-
curves.
0 = Linear
100 = full acc/dec
inc/dec tmes
P2.4.3
Acceleration time
2
0.1 3000.0 s 1.0 502
P2.4.4
Deceleration time
2
0.1 3000.0 s 1.0 503
P2.4.5 Brake chopper 0 4 0 504
0 = Disabled
1 = Used when
running
2 = External brake
chopper
3 = Used when
stopped/running
4 = used when
running (no test-
ing)
P2.4.6 Start function 0 2 0 505
0 = Ramp
1 = Flying start
2 = Conditional fly-
ing start
P2.4.7 Stop function 0 3 0 506
0 = Coasting
1 = Ramp
2 = Ramp+Run
enable coast
3 = Coast+Run
enable ramp
P2.4.8
DC braking cur-
rent
0.00 I
L
A 0.7 x I
H
507
