5.4.4 OUTPUT SIGNALS (CONTROL KEYPAD: MENU M2 -> G2.3
Table 37: Output signals, G2.3
Index Parameter Min Max Unit Default Cust ID Description
P2.3.1 *
AO1 signal selec-
tion
0.1 E.10 A.1 464
TTF programming
method used. See
Chapter 8.9 "Ter-
minal to function"
(TTF) programming
principle.
P2.3.2
Analogue output
function
0 14 1 307
0 = Not used
1 = Output freq. (0-
f
max
)
2 = Freq. refer-
ence (0-f
max
)
3 = Motor speed
(0-Motor nominal
speed)
4 = Motor current
(0-I
nMotor
)
5 = Motor torque
(0-T
nMotor
)
6 = Motor power
(0-P
nMotor
)
7 = Motor voltage
(0-U
nMotor
)
8 = DC-link volt
(0-1000V)
9 = PID controller
ref. value
10 = PID contr. act.
value 1
11 = PID contr. act.
value 2
12 = PID contr.
error value
13 = PID controller
output
14 = PT100 tem-
perature
P2.3.3
Analogue output
filter time
0.00 10.00 s 1.00 308
0 = No filtering
P2.3.4
Analogue output
inversion
0 1 0 309
0 = Not inverted
1 = Inverted
P2.3.5
Analogue output
minimum
0 1 0 310
0 = 0 mA (0 V)
1 = 4 mA (2 V)
PID CONTROL APPLICATION VACON · 111
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
5

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
