4.4.3 INPUT SIGNALS (CONTROL KEYPAD: MENU M2 -> G2.2)
Table 26: Input signals, G2.2
Index Parameter Min Max Unit Default Cust ID Description
P2.2.1 *** Start/Stop logic 0 6 0 300
Logic = 0
Ctrl sgn 1 = Start
forward
Ctrl sgn 2 = Start
reverse
Logic = 1
Ctrl sgn 1 = Start/
Stop
Ctrl sgn 2 = Reverse
Logic = 2
Ctrl sgn 1 = Start/
Stop
Ctrl sgn 2 = Run
enable
Logic = 3
Ctrl sgn 1 = Start
pulse (edge)
Ctrl sgn 2 = Stop
pulse
Logic = 4
Ctrl sgn 1 = Forward
pulse (edge)
Ctrl sgn 2 = Reverse
pulse (edge)
Logic = 5
Ctrl sgn 1 = Start
pulse (edge)
Ctrl sgn 2 = Reverse
pulse
Logic = 6
Ctrl sgn 1 = Start
pulse (edge)
Ctrl sgn 2 = Enable
pulse
