5.4.3 INPUT SIGNALS
Table 36: Input signals, G2.2
Index Parameter Min Max Unit Default Cust ID Description
P2.2.1 ** DIN2 function 0 13 1 319
0 = Not used
1 = External fault
cc
2 = External fault
oc
3 = Run enable
4 = Acc/Dec time
selection
5 = CP: I/O termi-
nal (ID125)
6 = CP: Keypad
(ID125)
7 = CP: Fieldbus
(ID125)
8 = Forward/
Reverse
9 = Jogging fre-
quency (cc)
10 = Fault reset
(cc)
11 = Acc/Dec pro-
hibit (cc)
12 = DC braking
command
13 = Motor pot. UP
(cc)
P2.2.2 **
DIN3 function 0 13 10 301
See above except:
13 = Motor pot.
DOWN (cc)
P2.2.3 ** DIN5 function 0 13 9 330
See above except:
13 = Enable PID
reference 2
VACON · 104 PID CONTROL APPLICATION
5
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
