Vacon NX series Applications Manual

Table 97: Drive control parameters, G2.4
Index Parameter Min Max Unit Default Cust ID Description
P2.4.9
DC braking time
at stop
0.00 600.00 s 0.00 508
0 = DC brake is off
at stop
P2.4.10
Frequency to start
DC braking during
ramp stop
0.10 10.00 Hz 1.50 515
P2.4.11
DC braking time
at start
0.00 600.00 s 0.00 516
0 = DC brake is off
at start
P2.4.12 * Flux brake 0 1 0 520
0 = Off
0 = On
P2.4.13
Flux braking cur-
rent
0.00 I
L
A I
H
519
7.4.6 PROHIBIT FREQUENCY PARAMETERS (CONTROL KEYPAD: MENU M2 -> G2.5)
Table 98: Prohibit frequency parameters, G2.5
Index Parameter Min Max Unit Default Cust ID Description
P2.5.1
Prohibit frequency
range 1 low limit
-1.00 320.00 Hz 0.00 509
0 = Not used
P2.5.2
Prohibit frequency
range 1 high limit
0.00 320.00 Hz 0.00 510
0 = Not used
P2.5.3
Prohibit frequency
range 2 low limit
0.00 320.00 Hz 0.00 511
0 = Not used
P2.5.4
Prohibit frequency
range 2 high limit
0.00 320.00 Hz 0.00 512
0 = Not used
P2.5.5
Prohibit frequency
range 3 low limit
0.00 320.00 Hz 0.00 513
0 = Not used
P2.5.6
Prohibit frequency
range 3 high limit
0.00 320.00 Hz 0.00 514
0 = Not used
P2.5.7
Prohibit acc./dec.
ramp
0.1 10.0 x 1.0 518
PUMP AND FAN CONTROL APPLICATION VACON · 223
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
7

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
