Vacon NX series Applications Manual

Table 38: Drive control parameters, G2.4
Index Parameter Min Max Unit Default Cust ID Description
P2.4.10
Frequency to start
DC braking during
ramp stop
0.10 10.00 Hz 1.50 515
P2.4.11
DC braking time
at start
0.00 600.00 s 0.00 516
0 = DC brake is off
at start
P2.4.12 * Flux brake 0 1 0 520
0 = Off
0 = On
P2.4.13
Flux braking cur-
rent
0.00 I
L
A I
H
519
5.4.6 PROHIBIT FREQUENCY PARAMETERS (CONTROL KEYPAD: MENU M2 -> G2.5)
Table 39: Prohibit frequency parameters, G2.5
Index Parameter Min Max Unit Default Cust ID Description
P2.5.1
Prohibit frequency
range 1 low limit
-1.00 320.00 Hz 0.00 509
0 = Not used
P2.5.2
Prohibit frequency
range 1 high limit
0.00 320.00 Hz 0.00 510
0 = Not used
P2.5.3
Prohibit frequency
range 2 low limit
0.00 320.00 Hz 0.00 511
0 = Not used
P2.5.4
Prohibit frequency
range 2 high limit
0.00 320.00 Hz 0.00 512
0 = Not used
P2.5.5
Prohibit frequency
range 3 low limit
0.00 320.00 Hz 0.00 513
0 = Not used
P2.5.6
Prohibit frequency
range 3 high limit
0.00 320.00 Hz 0.00 514
0 = Not used
P2.5.7
Prohibit acc./dec.
ramp
0.1 10.0 x 1.0 518
VACON · 116 PID CONTROL APPLICATION
5
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
