Vacon NX series Applications Manual

6.4.10 FIELDBUS PARAMETERS (CONTROL KEYPAD: MENU M2 ->G2.9)
Table 80: Fieldbus parameters
Index Parameter Min Max Unit Default Cust ID Description
P2.9.1
Fieldbus min
scale
0.00 320.00 Hz 0.00 850
P2.9.2
Fieldbus max
scale
0.00 320.00 Hz 0.00 851
P2.9.3
Fieldbus process
data out 1 selec-
tion
0 10000 1 852
The data that is
sent to fieldbus
with the ID of the
parameter or mon-
itor. The data is
scaled to an
unsigned 16-bit
format according
to the format on
the control panel.
For example, 25.5
on the display
agrees with 255.
P2.9.4
Fieldbus process
data out 2 selec-
tion
0 10000 2 853
Make the selection
of the Process
Data Out with the
parameter ID.
P2.9.5
Fieldbus process
data out 3 selec-
tion
0 10000 45 854
Make the selection
of the Process
Data Out with the
parameter ID.
P2.9.6
Fieldbus process
data out 4 selec-
tion
0 10000 4 855
Make the selection
of the Process
Data Out with the
parameter ID.
P2.9.7
Fieldbus process
data out 5 selec-
tion
0 10000 5 856
Make the selection
of the Process
Data Out with the
parameter ID.
P2.9.8
Fieldbus process
data out 6 selec-
tion
0 10000 6 857
Make the selection
of the Process
Data Out with the
parameter ID.
P2.9.9
Fieldbus process
data out 7 selec-
tion
0 10000 7 858
Make the selection
of the Process
Data Out with the
parameter ID.
MULTI-PURPOSE CONTROL APPLICATION VACON · 187
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
6

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
