Vacon NX series Applications Manual

Table 211: Current scaling in different size of units
Voltage Size Scale
208 - 240 Vac NX_2 0001 – 0011 100 – 0.01A
208 - 240 Vac NX_2 0012 – 0420 10 – 0.1A
380 - 500 Vac NX_5 0003 – 0007 100 – 0.01A
380 - 500 Vac NX_5 0009 – 0300 10 – 0.1A
380 - 500 Vac NX_5 0385 – 1 – 1A
525 - 690 Vac NX_6 0004 – 0013 100 – 0.01A
252 - 690 Vac NX_6 0018 – 10 – 0.1A
8.7.3 PROCESS DATA IN (MASTER -> SLAVE)
ControlWord, Reference and Process Data are used in All in One applications as follows:
Table 212: Basic, Standard, Local/Remote, Multi-Step applications
Data Value Unit Scale
Reference Speed reference % 0.01%
ControlWord
Start/Stop command
Fault reset command
- -
PD1 – PD8 Not used - -
NOTE!
Settings in the table below are factory defaults. See also parameter group G2.9.
VACON · 372 PARAMETER DESCRIPTIONS
8
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
