Vacon NX series Applications Manual

Table 37: Output signals, G2.3
Index Parameter Min Max Unit Default Cust ID Description
P2.3.6
Analogue output
scale
10 1000 % 100 311
P2.3.7
Digital output 1
function
0 23 1 312
0 = Not used
1 = Ready
2 = Run
3 = Fault
4 = Fault inverted
5 = FC overheat
warning
6 = Ext. fault or
warning
7 = Ref. fault or
warning
8 = Warning
9 = Reversed
10 = Preset speed
1
11 = At speed
12 = Mot. regulator
active
13 = OP freq. limit
superv. 1
14 = OP freq. limit
superv.2
15 = Torque limit
superv.
16 = Ref. limit
superv.
17 = Ext. brake
control
18 = Control place:
IO
19 = FC temp. limit
superv.
20 = Unrequested
rotation direction
21 = Ext. brake
control inverted
22 = Thermistor
fault/warn.
23 = Fieldbus DIN1
P2.3.8
RO1 function 0 23 2 313 As parameter 2.3.7
P2.3.9 RO2 function 0 23 3 314 As parameter 2.3.7
P2.3.10
Output frequency
limit 1 supervision
0 2 0 315
0 = No limit
1 = Low limit
supervision
2 = High limit
supervision
VACON · 112 PID CONTROL APPLICATION
5
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
