MC122 - MCP-4J Control Unit Section 7 - Specifications
91
Section 7 - Specifications
Item MCP-4J Unit, Horizontal
074xx087
074xx088
074xx089
074xx090
MCP-4J Unit, Vertical
074xx084
074xx085
074xx086
Control dimensions:
Height: 5.86" (x mm)
Depth: 10.11" (x mm)
Width: 9.95" (x mm)
Approximate weight:
12.5 lbs. (x)
Height: 12.5" (x mm)
Depth: 5.83” (x mm)
Width: 9.95" (x mm)
Approximate weight:
12.5 lbs. (2.49 kg)
Input voltage:
90-130, 200-240 VAC,
50-60 Hz (auto-selected)
90-130, 200-240 VAC,
50-60 Hz (auto-selected)
IP Rating
IP40
Number of channels:
4-channel operation with up to 10 programmable patterns per
channel
Glue pattern resolution:
0.01 in. or 1 mm
Minimum Glue Pattern Length
0” (0mm)
Maximum Glue Pattern Length
258.01” (6554mm)
Number of scanner inputs:
Up to 4 with scanner lockout
Glue pattern tolerance:
Less than 1 mm (0.4 inches) at 610 m/min (2000 ft/min)
Job storage memory:
100 jobs
Max Operating Ambient Temperature
60
o
C or 140
o
F
Miscellaneous:
Encoder-based or timer mode
Multi-valve, complex glue pattern capabilities
“Continuous” and “Stitch” pattern gluing
Adjustable minimum speed
Inch or metric calibration
CE compliant
Password protection for key system parameters
Integral fluid-flow control option (EPC)
Web break detection option
Batch count/production count
Programmable valve output voltages depending upon base
unit
Jam Detection (not on
horizontal units: 074xx087,
074xx088, 074xx089 or 074xx090)
USB software update
USB and Micro-SD backup and restore
Max Valve Chart
Valve Type 300E 400E/EC 524E 540E 900E 9020 MX MAC12 MAC24
Max Per Valve Channel
2 2 1 1 1 1 1 2 2
Max Per Unit
6 6 4 4 4 4 4 6 6
