VALCO MELTON MCP-4J User Manual

MC122 - MCP-4J Control Unit Section 3 - Basic features
21
MCP-4J Control, Vertical; with EPC (074xx085)
Front Panel
Figure 3-5. MCP-4J Control, Vertical; with EPC - Front View
Bottom Panel
Figure 3-6. MCP-4J Control, Vertical; with EPC - Bottom View
V
alve Output 1-4 (blue)
Scanner Input 1-4 (yellow)
Encoder Input
External Communication Port
Groundin
g
Screw
EPC2 Output
EPC Air
Pressure
Input* (see
note above)
Beacon & Relay Outputs for Jam
(not available in horizontal)
EPC Air Pressure Output
Ethernet Port
USB Port
AC Powe
r
Cable
Pump Power Connector
