Section 3 - Basic features
MC122 - MCP-4J Control Unit
26
MCP-4J Control, Horizontal; Dual External EPC (074xx090)
Front Panel
Figure 3-15. M
CP-4J Control, Horizontal; Dual
External EPC - Fr
ont View
Back Panel
Figure 3-16. M
CP-4J Control, Horizontal; Dual
External EPC - Botto
m View
V
alve Output 1-4 (blue)
Scanner Input 1-4 (yellow)
Encoder Input
Grounding Screw
EPC2 Output
EPC1 Output
Ethernet Port
USB Port
Pump Power Connector
AC Power
Cable
35
37
