MC122 - MCP-4J Control Unit Section 4 - Programming
53
Speed Settings
V-min (Minimum Product Speed) - The minimum speed the machine must reach before glue is applied to the
product.
V-jog (Jog Speed) - Between minimum speed and jog speed, a glue line will be separated into dots in order to make
the glue volume even more precise, when Jog Mode is enabled.
Valve Type
The Plus/Minus Buttons can be used to scroll through the
different valve types available.
Scanner Settings
Minimum Product Length - The length of a product that is necessary to trigger a start signal. If there are tabs and/or
dust causing false trigger signals, increase the Minimum Product Length.
Maximum Product Length - (Only active in Auto Glue) Determines the maximum pattern length in Auto Glue Mode.
If this is set to “0” the function is disabled. In Auto Glue, the output will remain on as long as the input is active (start).
To Next Page
