VALCO MELTON MCP-4J User Manual

MC122 - MCP-4J Control Unit Section 3 - Basic features
25
MCP-4J Control, Horizontal; Folding Carton, Tipsealer
(074xx089)
Front Panel
Figure 3-13. MCP-4J Control, Horizontal; Folding Carton, Tipsealer - Front View
Back Panel
Figure 3-14. MCP-4J Control, Horizontal; Folding Carton, Tipsealer - Bottom View
V
alve Output 1-4 (blue)
Scanner Input 1-4 (yellow)
Encoder Input
Groundin
g
Screw
EPC2 Output
EPC Air
Pressure
Input* (see
note above)
EPC Air
Pressure Output
Ethernet Port
USB Port
Pump Power Connector
AC Powe
r
Cable
