MC122 - MCP-4J Control Unit
Section 4 - Programming
47
Enter Password
To view, setup, and use the various functions of the MCP-4J
Control Unit, pa
sswords are used. This ensures safety
and security of all settings. To enter a password, do the followi
ng:
