Appendix B - System Connectivity MC122 - MCP-4J Control Unit
130
Gluer Connection Setup with 1 Network Card - Continued
3. Right click on the device labeled ‘NIC3’ and select properties.
4. Next, click on ‘Internet Protocol Version 4’.
5. Then click on the ‘Properties’ button.
6. Select the ‘Use the following IP address’ option. As above, set the following:
IP address to 192.168.30.1
Subnet mask to 255.255.255.0
7. Click the ‘OK’ button, and “close”.
8. Plug the Gluer Ethernet cable into the port “NIC3”.
To Next Page
