1.4 Case Parts
The external components of a VR100 consist of:
 a hydrophone
 a USB cable
 a battery charger
 headphones
These components are all connected to the VR100 through connectors on the side of the case.
The case has a pressure relief vent to allow any pressure build-up in the case to release before the case is
opened. A manufacture’s tag is attached to the vent and should not be removed. Removing the tag may
damage the vent.
Lid:
Must be raised to access
Front Panel controls.
External connectors (left to right):
hydrophone, USB cable, battery charger,
headphones. Each connector has a
protective cover. See section 1.5.
Pressure relief vent:
Do not remove red tag!
Handle: Rubber coated
for additional grip.
Serial Number label: Lists the serial
number and identifies the model.
Latch: Two latches
keep the lid securely
in place when
VR100 is not in use.
