VEMCO – VR100 Manual 28 May 2018 26
3. Click the Update button. The tag is now added to the list shown in the PC Managed Setup half of the
window (on left).
The tag just setup has not yet been entered in the VR100 receiver. It must be transferred to the Receiver
Setup list (see section 3.8.3).
3.8.2 Edit a Sensor Tag
Sensor transmitters that have already been entered can be edited. Follow the steps below to edit an existing
sensor transmitter.
1. Highlight the desired tag in the PC Managed Setup list (left side of Tag Manager window). The
information already entered about that tag is displayed in the bottom left corner of the window but is not
accessible for editing.
2. Click the “Edit” box in the bottom left corner of the window.
3. Edit the tag information as needed.
4. Click the Update button.
3.8.3 Transfer PC Managed Setup List to Receiver Setup List
The tag and map information listed in the PC Managed Setup half of the Tag Manager window (see section
3.8) must be transferred to the Receiver Setup half of the window to be downloaded to the VR100 receiver.
Follow the steps listed below to perform such a transfer.
1. Open the Tag Manager window (see section 3.8).
2. Enter the tag information by either entering it in the window (see section 3.8.1) or by opening a
previously saved resource file (see section 6.6.3.1).
3. Select the desired tag(s) or map(s) in the PC Managed Setup list (left half of window) by clicking it once
with the mouse.
TIP: To select more than one tag at once, select the first tag then hold the Control key on the computer’s
keyboard while you select the other tags with the mouse arrow. Press the Shift key instead to select
blocks of tags.
4. Click the right-pointing arrow located in the middle of the Tag Manager window or drag and drop the
selected tag(s) to the Receiver Setup. The selected tag setup is transferred to the Receiver Setup list (right
half of window) and automatically transferred to the VR100.
NOTE: For coded two-sensor tags, two separate sensor tag entries are required – one for each tag ID
(sensor). Since the VR100 does not allow duplicate serial numbers in the sensor database, the serial
number for the second sensor entry must be different than the first sensor entry. We recommend that
you use the serial number provided on the specification sheet for the first sensor entry, and the same
serial number with a prefix for the second sensor entry.
For example, use “20” as the prefix: Sensor 1 SN: 1034857 Sensor 2 SN: 201034857
Adding a tag does not automatically send it to the VR100.
Transfer the tag to the Receiver Setup list to add it to the VR100.
