6 Additional Information
6.1 Menu Outlines
VR100 operations are separated into three groups: monitoring, configuring, and transponding (transponding
is only available on the VR100-200 model and requires additional equipment). Two of these groups,
configuring and transponding, contain multi-layered menu structures that are explained in sections 6.1.2 and
6.1.3. The VR100 PC software also contains a menu structure and has been included in section 6.1.4.
Each sub-menu option is associated with a number shown on the screen to the left of the selection, as shown
in the screen below. Selecting a sub-menu option can be performed by using the up and down arrows on the
front panel to move the cursor to the desired sub-menu and then pressing the right selection button for the
Select command. A down arrow in the screen indicates that the list extends downward and the remainder of
the list can be accessed by using the down button. An up arrow will appear in the top line if the list extends
above the items shown.
It’s also possible to select a sub-menu by pressing the corresponding number on
the keypad. The menu numbers are included in the menu structure maps at the
beginning of sections 6.1.2 and 6.1.3 for easy reference.
6.1.1 VR100 Main Screen
The three menu groups within the VR100 are all accessed from the VR100 Main screen. How these menus
are accessed differs slightly when using the VR100-200 model compared to the older VR100 model.
Accessing the Monitor features on the VR100 is always accomplished by pressing the left selection button
while the VR100 displays the Main screen (shown below). How to monitor tags is described in section 4.2.
On the VR100-200 model, with firmware version 3.3.1 or greater installed, the Transponding menu is
accessed by pressing the right selection button as shown in the drawing on the right below. The features of
the Transponding menu that are most commonly used in the field are described in section 4.4 with the
remaining features being described in section 6.1.3.
2014 05 28 16:45:11-
GPS: Getting Fix
Sats: 0
Monitor Transpond
2014 05 28 16:45:11-
GPS: Getting Fix
Sats: 0
Monitor Config
1 Channel
2 System
3 Code Map
To Next Page
