2.3.3 Setup a Channel to Monitor a Coded Tag
A channel can be set up to monitor a large number of coded tags on one frequency.
From the Main screen:
1. Select Config (see section 6.1.2.1).
2. Press “1” on the keypad.
3. Select the desired channel number on the keypad, or use the arrow buttons to move through the list of
channels until the cursor is over the desired channel.
4. Press the right selection button for “Configure”. The channel’s configuration is displayed in a
summary screen.
5. Select “Edit” with the left selection button to change the channel’s configuration or “Accept” with the
right selection button to return to the channel screen.
6. Use the up and down arrows to cycle through the four tag types until “Coded” is displayed and then
select “Next”.
7. Enter the frequency (usually 69 or 180 kHz) on the key pad and select “Next”.
NOTE: If you make an error, keep pressing the first number until the cursor returns to the first digit
place.
8. Select the code map (see section 7.1.1) to be used on this channel by pressing the arrow buttons to
scroll through the list of code maps.
9. Press the right selection button to select “Next”.
10. Review the summary screen to verify that the information is correct.
11. Press the right selection button for “Accept”.
12. Select the channel to be set up by either using the up/down arrows or pressing the corresponding
number on the keypad.
13. Press the left selection button for “Set on” to turn this channel on. If you don’t want to turn the
channel on at this time, perform steps 12 and 13 at a future time, or see section 2.3.5.
2.3.4 Setup a Channel for Transponding
The transponding process uses Channel 8 to receive communication from the receiver. VR100 receivers
shipped after March 2015 have Channel 8 setup for transponding by default, but if your receiver is slightly
older or the channel setup have been altered, then follow the steps listed below to setup the channel correctly.
From the Main screen:
1. Select Config (see section 6.1.2.1).
2. Press “1” on the keypad.
3. Press “8” on the keypad, or use the arrow buttons to move through the list of channels until the cursor
is over the “8”.
4. Press the right selection button for “Configure”. The channel’s current configuration is displayed in a
summary screen.
5. Select “Edit” with the left selection button to change the channel’s configuration or “Accept” with the
right selection button to return to the channel screen.
6. Use the up and down arrows to cycle through the four tag types until “Transponding” is displayed
and then select “Next”.
A warning will appear when transponding is selected
and Channel 8 is not configured properly.
