PROGRAMMING FOR THE OPTIONAL T1 AND ISDN (T1/PRI) CARDS DX-120 Programming Manual
- 162 -
Programming for a T1 Card via the DET (continued)
Make the appropriate Caller ID Settings:
From the DB Item Select screen (see steps 1 through 3 on page 159):
4) Enter 07-03-06.
5) Press save to display the Caller ID screen.
6) Press show to display the Start Digit screen.
7) Press chg until the appropriate alphanumeric setting (using A-D, 0-9, * or #) appears.
8) Press next to display End Digit screen.
9) Press chg until the appropriate alphanumeric setting (using A-D, 0-9, * or #) appears.
10)Press next to display the Max Length setting.
11) Press chg until the appropriate setting (0-15) appears.
12) Press next to display the Channel setting screen.
13) Press show to display the Trunk screen (now go to step 6 in “Make the appropriate Channel Settings:”
below).
OR
Press the volume UP button to return to the DB Item Selection screen.
OR
Exit programming (see “Exiting Database Administration” on page 27).
Make the appropriate Channel Settings:
From the DB Item Select screen (see steps 1 through 3 on page 159):
4) Enter 07-03-07.
5) Press save to display the Channel setting screen.
6) Press show to display the Trunk screen.
7) Enter the appropriate directory number (using digits 0-9).
8) Press save to store the settings.
9) Press next to display the Channel Type screen.
10) Press chg until the appropriate type is displayed.
• WINK: START E&M is the default.
11) Press save to store the settings.
12) Press next (twice) to display the Padding screen.
13) Press show to display the TX Gain screen (now go to step 6 in “Make the appropriate Padding Settings:”
below).
OR
Press the volume UP button to return to the DB Item Selection screen.
OR
Exit programming (see “Exiting Database Administration” on page 27).
Programming for a T1 Card via the DET (continued on next page)
