PROGRAMMING FOR THE OPTIONAL T1 AND ISDN (T1/PRI) CARDS DX-120 Programming Manual
- 168 -
Programming for an ISDN (T1/PRI) Card via the DET (continued)
Setting COLP (Connected Line Identification Presentation:
From the DB Item Select screen (see steps 1 through 3 on page 167):
4) Enter 07-04-02.
5) Press save to display the COLP screen.
6) Press chg to change the setting.
• If you want to leave the current setting as is, skip to the next step.
7) Press next to display Site Number screen (now go to step 6 in “Setting the Site Number:” below).
OR
Press the volume UP button to return to the DB Item Selection screen.
OR
Exit programming (see “Exiting Database Administration” on page 27).
Setting the Site Number:
From the DB Item Select screen (see steps 1 through 3 on page 167):
4) Enter 07-04-03.
5) Press save to display the Site Number screen.
6) Press show to display the current setting.
• If you want to leave the current setting as is, skip to step 9.
7) Press chg.
8) Enter the site number (using digits 0-9).
9) Press save to store the setting.
10) Press next display the Prefix screen (now go to step 6 in “Setting the Prefix:” below).
OR
Press the volume UP button to return to the DB Item Selection screen.
OR
Exit programming (see “Exiting Database Administration” on page 27).
Programming for an ISDN (T1/PRI) Card via the DET (continued on next page)
