Edge 700 Phone - 24 Button 6-11
About Wave Digital Phones
Wave Phone User Guide
Edge 700 Phone - 24 Button
Note: The Edge 100 12- and 24-button phones are discontinued. Existing warranties supported.
Note: The Edge 700 - 24 module phone can have full duplexing capability when the appropriate
duplexing module is connected (see item 3 above and on next page).
6 - Three Softkeys (not programmable)
16 - SPEAKER
14 - VOLUME (down)/(up)
8 - Microphone Opening
(located under the front panel)
2 - Speaker
(located under the handset)
4 - Display
7 - Twenty-four (PGM)
Pre-programmed Buttons
13 - Scroll and
Select Button
1 - Handset
17 - Headset (2.5mm) Jack
(located behind front panel)
3 - Flat (Ribbon) Cable (located on the back of the phone)
5 - Message Waiting Light
15 - HOLD
9 - TAP | 10 - TRANS
11 - SHIFT | 12 - MUTE
