Vertical Wave - Impact SCS (8024) - 24 Button

Impact SCS (8024) - 24 button 6-15
About Wave Digital Phones
Wave Phone User Guide
Impact SCS (8024) - 24 button
3 - Three Softkeys (not programmable)
7 - Microphone Opening
(located under the front panel)
2 - Handsfree Speaker
5 - Twenty-four
Pre-programmed (PGM
Buttons
1 - Handset
16 - Headset (Auxiliary) Jack
(located behind front panel)
4 - Display
8 - SHIFT
6 - MUTE
9 - SPEAKER
12 - TAP
11 - INTERCOM
13 - Volume Down
14 - HOLD
15 - TRANS/CONF
10 - Volume
Up
