Figure 9.8 LBS Adapter
Item Description Item Description
1 Power Port 5 COM2
2 LED1 6 Green LED
3 COM1 7 Switch
4 Yellow LED
For details about how to install and connect cables, see Dual Bus UPS LBSTM Expander/Adapter Installation Manual.
164 Proprietary and Confidential ©2023 Vertiv Group Corp.
9 Vertiv™ Liebert® APM2 Option
Configurations
Vertiv™ Liebert® APM2 30 to 120 kVA Modular UPS User Manual
