Figure 3.6 Layout of 120 kVA Modules
Item Description Item Description
1 Cabinet with built-in battery module 7 Lead-acid battery module
2 Control module 8 Control module
3 Power module 9 Power module
4 Bypass module 10 Bypass module
5 Lead-acid battery module 11 BMS module
6 BMS module
