Vertiv Liebert STS2/PDU - Altitude

Vertiv™ | Liebert
®
STS2
™
100-1000A, 50/60Hz User Manual | Rev. 12 | 11/2017 7
3.4 Altitude
The standard units are designed for full load operation up to 4000 feet (1200m) above sea level. Above 4000
feet (1200m), output current is derated by 6% per 1000 feet.
Operation at full load at a higher altitude can be accommodated in ambient temperatures less than 104°F (40°C)
ambient. Figure 1 shows the maximum allowable ambient temperature for full load operation at altitudes above
4000 feet (1200 m).
Figure 1 Maximum ambient temperature for full load operation at higher altitudes
Altitude, Feet (M) Above Sea Level
86.0 (30)
87.8 (31)
89.6 (32)
91.4 (33)
93.2 (34)
95.0 (35)
96.8 (36)
98.6 (37)
100.4 (38)
102.2 (39)
104.0 (40)
Maximum Ambient
Temperature, °F (°C)
4000
(1200)
4500
(1372)
5000
(1524)
5500
(1676)
6000
(1829)
6500
(1981)
7000
(2134)
7500
(2286)
8000
(2438)
8500
(2591)
9000
(2743)
9500
(2896)
10,000
(3048)
0
