100-1000A, 50/60Hz User Manual | Rev. 12 | 11/2017 43
Figure 30 Installation drawing, seismic floor stand 100-250A
Rear Upper Liebert STS2 Bracket
PS215001
Rev. 1
Front
Front
Rear
Rear
Rear
Front
Front Upper
Liebert STS2
Bracket
DETAIL C
Front
Front Upper
Liebert STS2 Bracket
Rear Lower
Liebert STS2 Bracket
Rear Upper
Liebert STS2
Bracket
FIGURE 1
Bottom of Liebert STS2
with Upper Brackets
FIGURE 3
Top of Floor Stand
with Lower Rear Mounting Bracket
FIGURE 2
Right Side of Liebert STS2
with Upper Brackets
FIGURE 4
Right Side of Floor Stand
with Lower Rear Mounting Bracket
Rear
Side
2 Places
Cap Screw M12-1.75x40mm
M12 Split Lock Washer
M12 Flat Washer
See Detail C
2 Places
Cap Screw M12-1.75x40mm
M12 Split Lock Washer
M12 Flat Washer
3 Places
Cap Screw M12-1.75x40mm
M12 Split Lock Washer
M12 Flat Washer
Rear Lower
Bracket
Leveling
Foot
Nut
Leveling
Foot
See Drawings PS215000, PS215002 and PS215003
for details.
