Vertiv™ | Liebert
®
STS2
™
100-1000A, 50/60Hz User Manual | Rev. 12 | 11/2017 61
10.0 OPERATING INSTRUCTIONS FOR THE
TOUCHSCREEN INTERFACE
After the initial equipment startup, the following operating guidelines can be used for standard equipment
operation. These guidelines should be reviewed for any special equipment modifications, special site conditions,
or company policies that may require changes to the standard equipment operation.
All programmable functions are preset at the factory to enable the unit to be brought up without the need to
enter all selectable parameters.
This section refers to the LCD touchscreen display. This display is discussed in more detail later in the manual.
See 13.0 - Liebert STS2 Touchscreen Display.
See Figures 13 - 18 for circuit breaker locations.
CAUTION
Before the unit is placed into service for the first time, after equipment relocation, or after the equipment
has been de-energized for an extended period of time, a thorough equipment inspection and supervised
startup by qualified personnel are strongly recommended. Contact your local Vertiv representative or
Vertiv Services at 800-543-2378 to arrange for equipment inspection and startup.
NOTE
If the front panel of your Liebert STS2 has LED’s and push buttons instead of the touchscreen interface, refer to
14.0 - Operating the Liebert STS2 LED Display for operating instructions.
